10 COMMON POWER PROBLEMS

AC Blackout.png

AC BLACKOUT

A total loss of utility power occurring for more than 2 cycles

Frequency Variation.png

FREQUENCY VARIATION

Frequency change from nominal 60Hz or 50Hz. Operation from engine genera- tors can produce frequency variations


BROWN OUT

Long-term reduced line voltage for an extended period of a few minutes to a few days

Normal Mode Noise.png

NORMAL MODE NOISE

High frequency electrical waveform between line (L) and neutral (N) caused by RFI or EMI interference

Voltage Surge.png

VOLTAGE SURGE

Short-term high voltage above 110% of nominal for several cycles

Harmonic Distortion.png

HARMONIC DISTORTION

Distortion of the normal waveform generally caused by nonlinear loads such as rectifiers, switch mode power supplies, and variable frequency drives

Power Sag.png

POWER SAG

Short-term low voltage caused by starting inrush current of large equipment, utility switching, or a temporary overload

Switching Transient.png

SWITCHING TRANSIENT

Make this your own. Click here to add the content you want.


OVERVOLTAGE

Extended periods of increased line voltage ranging from a few minutes to a few days

Common Mode Noise.png

COMMON MODE NOISE

Electrical Interference that is measured between ground and either neutral (N) or line (L) of a typical AC power line
